- VITON-200 high temperature tubing
- 【Brief 】：
2:1 shrinking, black
- 【Series】：PTFE FEP Kynar Viton
- Product description
VITON-200
Flexible, high-temperature, solvent-resistant Viton tubing
1) Application
With superior resistance to high and low temperature, fuids, solvents and corrosive chemical, VITON-200 is particularly suitable for applications that require heat resistance, such as electric and hydraulic systems near engines and fuel tanks of airplanes and vehicles, and resistance to chemical solvents. It is particularly used in applications require high temperature (200℃) resistance or in chemically exposed environments. It can be used in applications where additional protection against weather, ultraviolet radiation and ozone degradation is needed. Used for insulation and strain relief on appliances and for protection of electronic components.
2) Features/Benefits
Shrink ratio: 2:1
Excellent resistance to high temperatures, fluids, solvents, corrosive chemicals and radiation.
Extreme resistance to fuels.
High flame-retardance.
Conform to European RoHS environmental directive.
3) Operating Temperature Range
Operating temperature range: -65℃~200℃
Minimum shrink temperature: 150℃
Minimum full recovery temperature: 220℃
4) Specifications/Standards
AMS-DTL-23053/13
5) Product sizes
mm/inch
Size
Inside diameter
Wall thickness
Standard length
(m/spool)
As supplied（min.）
After recovery（max.）
After recovery
1/8
3.2（0.125）
1.6（0.062）
0.76±0.13（0.030±0.005）
50
3/16
4.8（0.187）
2.4（0.093）
0.89±0.18（0.035±0.007）
50
1/4
6.4（0.250）
3.2（0.125）
0.89±0.18（0.035±0.007）
50
3/8
9.5（0.375）
4.8（0.187）
0.89±0.18（0.035±0.007）
50
1/2
12.7（0.500）
6.4（0.250）
0.89±0.18（0.035±0.007）
30
3/4
19.1（0.750）
9.5（0.375）
1.07±0.21（0.042±0.008）
30
1
25.4（1.000）
12.7（0.500）
1.25±0.30（0.049±0.011）
30
1 1/2
38.1（1.500）
19.0（0.750）
1.40±0.38（0.055±0.015）
30
2
50.8（2.000）
25.4（1.000）
1.65±0.43（0.055±0.017）
30
6) Ordering InformationColor
Standard: Black (-BK)
Nonstandard colors can be available upon request.
Nonstandard size
Nonstandard sizes are available upon request.
Standard packaging
On spools.
Ordering description
Specify product type, size (mm or inch) and color.
